MegaQwen: Hitting the Architectural Ceiling of Cooperative CUDA Megakernels

A deep dive into building and exhaustively optimizing a fused transformer megakernel. We achieved 530 tok/s on Qwen3-0.6B - then discovered why that's the limit.

Results

The megakernel beats TensorRT-LLM at short contexts (530 vs 355 tok/s) with zero compilation overhead. But more interesting than the result is why we couldn't go faster.

The Architecture

A megakernel fuses an entire transformer block into one CUDA kernel launch. All 28 layers of Qwen3-0.6B run as one kernel invocation, with intermediate activations staying in registers and L2 cache instead of global memory.

The challenge: transformer layers have dependencies. Attention can't start until QKV projection finishes. We solve this with cooperative groups - CUDA's mechanism for grid-wide synchronization:

#include <cooperative_groups.h>
namespace cg = cooperative_groups;

__global__ void megakernel(...) {
    cg::grid_group grid = cg::this_grid();

    for (int layer = 0; layer < 28; layer++) {
        // All 82 blocks compute QKV projection
        compute_qkv(block_id, ...);
        grid.sync();  // Wait for all blocks

        // 16 blocks compute attention (one per Q head)
        // Other 66 blocks prefetch MLP weights
        if (block_id < 16) {
            compute_attention(block_id, ...);
        } else {
            prefetch_mlp_weights(block_id - 16, ...);
        }
        grid.sync();

        // All blocks compute MLP
        compute_mlp(block_id, ...);
        grid.sync();
    }
}

Each decode step requires ~225 grid.sync() calls (8 per layer x 28 layers + extras). This becomes important later.

The Optimization Journey

After the initial implementation hit 170 tok/s, we spent weeks trying every optimization we could think of.

What Worked

The block divergence optimization was the breakthrough. During attention, only 16 of 82 blocks actually compute (one per Q head). The other 66 blocks were sitting idle at grid.sync(). By having them prefetch MLP weights using __ldg(), those weights are already in L2 cache when MLP starts.

What Didn't Work

The warp specialization experiment was particularly instructive. We hypothesized that dedicating some warps to prefetching while others compute would help:

All compute is optimal. This was the first hint that we weren't bandwidth-bound.

The Root Cause

After exhaustive optimization, we finally profiled properly:

We're using only 5% of available memory bandwidth.

The kernel isn't memory-bound. It's latency-bound by grid synchronization. With 140+ grid.sync() calls at ~0.7us each, we spend ~100us per token just waiting at barriers.

This explains why warp-level prefetching didn't help: we're not waiting on memory, we're waiting on synchronization. Adding more prefetching when the bottleneck is sync overhead is pointless.

Cooperative Groups vs CUDA Graphs

A natural question: why not split the kernel at grid.sync() points and use CUDA graphs instead?

Cooperative groups actually wins by 19.7 us over CUDA graphs for pure sync overhead. But the bigger issue: splitting would require writing all intermediate buffers to global memory between kernels. That's ~2.7 MB of extra memory traffic per token - 6x more costly than the sync overhead difference.

The Architectural Ceiling

~530 tok/s is the architectural ceiling for batch=1 bf16 cooperative megakernels on RTX 3090.

To exceed this limit, you need to fundamentally change the approach:

Fair Comparison (Devil's Advocate)

Credit where it's due: TensorRT-LLM, vLLM, SGLang, and other frameworks are excellently optimized for production workloads with dynamic shapes, variable batch sizes, and long contexts. This megakernel exploits several advantages they intentionally don't:

1. Static shapes: All dimensions (hidden size, head count, MLP width) are compile-time constants. Production frameworks must handle arbitrary model architectures at runtime.
2. Short context bias: The benchmarks favor position 1-100 where KV cache overhead is minimal. At longer contexts, TensorRT-LLM's consistent 355 tok/s beats the megakernel's degradation to 158 tok/s.
3. Single model, single GPU: No tensor parallelism, no continuous batching, no dynamic memory allocation. Real serving systems need all of these.
4. Learning exercise: This project was built to understand GPU optimization, not to replace production inference engines.

The speedup is real, but it comes from exploiting a narrow regime (batch=1, short context, static shapes) where the texture cache (__ldg()) provides massive benefits by keeping weights in the read-only cache path while L1/L2 handles activations. Production frameworks can't make these assumptions.

TL;DR: Use TensorRT-LLM or vLLM for production. Use this to learn how GPUs actually work.

Lessons Learned

1. Profile before optimizing. We assumed memory bandwidth was the issue. It wasn't. The 5% bandwidth utilization revealed we're latency-bound.
2. Cooperative kernels have inherent limits. grid.sync() overhead dominates at high sync counts. For 140+ syncs per token, this is unavoidable.
3. Block-level parallelism matters. The +2x from L2 prefetching came from utilizing idle blocks during attention. This was the only substantial win.
4. GPU caches are better than you think. L1/L2 handle repeated reads effectively. Explicit shared memory caching often adds overhead without benefit.
5. SASS analysis is essential. Looking at actual assembly revealed whether optimizations (like 128-bit loads) were actually being applied.

Try It

git clone https://github.com/Infatoshi/megakernels.git
cd megakernels
uv venv && source .venv/bin/activate
uv pip install torch --index-url https://download.pytorch.org/whl/cu121
uv pip install transformers triton

# Interactive chat
python chat.py

# Run benchmarks
python experiments/framework_bench/benchmark_suite.py

# Verify correctness
python verify_correctness.py

• GitHub: github.com/Infatoshi/megakernels
• Full optimization journey: DEVLOG.md
• Benchmark data: experiments/RESULTS.md
• Memory analysis: docs/MEMORY_ANALYSIS.md

February 2026
